    Fujitsu Cash Handling Component GSR50 Scalable Cash Recycler ATM Parts

    Ask Lasest Price
    Brand Name : Fujitsu
    Model Number : GSR50
    Price : Contact us
    Payment Terms : T/T
    Supply Ability : 100000 units per year
    Delivery Time : 7-14 working
    • Product Details
    • Company Profile

    Fujitsu Cash Handling Component GSR50 Scalable Cash Recycler ATM Parts

    Fujitsu Cash Handling Component GSR50 Scalable Cash Recycler ATM Parts


    Overview
    The GSR50 is a compact and scalable recycler designed to support multiple industry verticals including retail, financial,transportation, etc. lts basic function, to accept, dispense, recycle denominate and detect counterfeit bils makes it anideal choice for most applications.


    Key Feature

    • Cash in/out slot: Semi-bunch mechanism with the short edge first
    • Bunch acceptor
    • High performance bill validationTransport speed: Max. 3 notes/second
    • High capacity cash box: Max. 1,500 notes/box
    • Selectable configuration of the number of cashbox module, recycling module and loading module.· Exception box for counterfeit as option

    Specifications

    Dimension (Wx Dx H)160mm x 600mm × 312-800mm*Up to configuration
    Weight11.7-32.2kg (Excluded notes weight)*Up to configuration
    Acceptable bunch size10mm height
    Dispensable bunch size6mm height
    Transport SpeedMax 3 notes/second
    Capacity
    Cash boxMax. 1,500 notes (Ilnner area: 225mm)
    Recycling stackerDual drum: Max.60 notes / drum ( 120 notes / recycling stacker)
    Loading cassetteMax.500 notes (Inner area: 60mm)
    Exception boxMax.20 notes (Inner area: 40mm)

    The product specifications are subject to change without prior notice.



    What Fujitsu GSR50 Modules we can supply are as below:

    P/NDescription
    497-0517268 4970517268Fujitsu GSR50 Top module
    KD04013-C001 KD04013C001Fujitsu GSR50 Recycling module(stacker+Frame)
    KD04013-D001 KD04013D001Fujitsu GSR50 Recycling Frame
    KD04014-D001 KD04014D001Fujitsu GSR50 Recycling stacker
    KD04017-C001 KD04017C001Fujitsu GSR50 Loading module(Cassette+Frame)
    KD04017-D001 KD04017D001Fujitsu GSR50 Loading Frame
    KD04018-D001 KD04018D001Fujitsu GSR50 Loading Cassette
    KD04015-C001 KD04015C001Fujitsu GSR50 Cash box module(Frame+box)
    KD04015-D001 KD04015D001Fujitsu GSR50 Cash box Frame
    KD04016-D001 KD04016D001Fujitsu GSR50 Cash box
